ZyForgeSim (ForgeSim)

ForgeSim is a discrete-event simulator for Kubernetes-native GPU scheduling inspired by Zyvor Forge ( https://zyvor.dev/forge ). It models clusters, MIG, topology, tenants, quotas, gang scheduling, and AI workloads, enabling scheduler development, RL research, and performance evaluation without requiring physical NVIDIA GPUs.

▶ Watch the demo — Forge (production GPU/Kubernetes control plane) and ZyForgeSim (its simulator) running side by side, ~3 min.

Architecture

Rust core — event engine, cluster model, schedulers, metrics, Forge bundle loader, inference timing model
Python API — PyO3 bindings, Forge CRD adapters, Gymnasium env, visualization, FastAPI server, AIPerf adapters
Web UI — Next.js dashboard (runs, benchmark, what-if) + Rich CLI live dashboard

Installation

Container images (GHCR)

Pre-built images are published to GitHub Container Registry on every release:

docker pull ghcr.io/hypersdk/forgesim-api:latest
docker pull ghcr.io/hypersdk/forgesim-web:latest

# Run the API + web dashboard locally:
docker network create forgesim 2>/dev/null || true
docker run -d --name forgesim-api --network forgesim -p 8080:8080 \
  ghcr.io/hypersdk/forgesim-api:latest
docker run -d --name forgesim-web --network forgesim -p 3000:3000 \
  -e FORGESIM_API_URL=http://forgesim-api:8080 \
  ghcr.io/hypersdk/forgesim-web:latest

Then open http://localhost:3000 (default login Admin / Admin@321 — override via FORGESIM_DASHBOARD_USER / FORGESIM_DASHBOARD_PASSWORD env vars on the web container).

Pin a specific release instead of latest with ghcr.io/hypersdk/forgesim-api:vX.Y.Z.

Kubernetes

cd deploy/kubernetes
cp secret.example.yaml secret.yaml   # edit credentials
kubectl apply -f secret.yaml
kubectl apply -k .

See deploy/kubernetes/README.md for the full guide (local kind/minikube cluster, Ingress, remote k3s deploy via scripts/deploy-remote.sh).

From source (Rust CLI + Python bindings)

git clone https://github.com/hypersdk/ZyForgeSim.git
cd ZyForgeSim
cargo build --release -p forgesim-cli

# Optional: Python bindings + web API (builds the PyO3 extension)
./scripts/setup_dev.sh
source .venv/bin/activate
pip install -e '.[server]'     # FastAPI / uvicorn (web API)

See CONTRIBUTING.md for the full dev setup, including optional viz, rl, and dashboard extras.

Quick start

Internal workload (M1)

cargo run -p forgesim-cli -- run --config configs/clusters/small_h100.yaml

Forge export bundle (M2 — test Forge without GPUs)

Export from a Forge cluster:

mkdir -p forge-export/{jobs,cluster,quotas}
kubectl get fabricaijobs -A -o yaml > forge-export/jobs/all.yaml
kubectl get fabricgpunodes -o yaml > forge-export/cluster/nodes.yaml
kubectl get fabricquotas -A -o yaml > forge-export/quotas/all.yaml

Add calibrated runtime profiles in configs/profiles/ (see configs/profiles/gpt-13b.yaml).
Run simulation:

cargo run -p forgesim-cli -- run \
  --forge-bundle forge-export \
  --profiles-dir configs/profiles

Or use the included fixture:

cargo run -p forgesim-cli -- run \
  --forge-bundle tests/fixtures/forge \
  --profiles-dir configs/profiles

Scheduler policies (M6)

# Priority: highest priority first, no preemption
cargo run -p forgesim-cli -- run --config configs/clusters/priority_scheduler.yaml

# Preemptive: evict lower-priority running jobs for higher-priority arrivals
cargo run -p forgesim-cli -- run --config configs/clusters/preemption_preemptive.yaml

# Forge bundle with scheduler flag (fifo | priority | preemptive | forge | bestfit)
cargo run -p forgesim-cli -- run \
  --forge-bundle tests/fixtures/forge \
  --scheduler forge

Scheduler trace replay (M3 — compare vs production Forge)

cargo run -p forgesim-cli -- replay \
  --trace tests/fixtures/traces/fifo_match.jsonl \
  --config configs/clusters/single_gpu.yaml

Writes outputs/trace_diff.json with oracle vs FIFO placement diffs.

MIG simulation (M4)

cargo run -p forgesim-cli -- run --config configs/clusters/mig_single.yaml

MIG jobs use mig_profile and mig_count (Forge spec.mig) to allocate fractional GPU slices with a simulated reconfiguration delay.

Topology + gang placement (M5 / M6)

# NVLink-domain-aware placement; cross-domain jobs inflate runtime
cargo run -p forgesim-cli -- run --config configs/clusters/topology_penalty.yaml

# Gang jobs require GPUs spread across gang_size_nodes distinct nodes
cargo run -p forgesim-cli -- run --config configs/clusters/gang_m6.yaml

# Gang timeout fails jobs that cannot be placed in time (jobs_failed metric)
cargo run -p forgesim-cli -- run --config configs/clusters/gang_timeout_m6.yaml

Inference + LLM serving metrics (P1)

cargo run -p forgesim-cli -- run \
  --config configs/clusters/inference_llama.yaml \
  --output outputs/inference_metrics.json

Uses profile v2 fields (prefill_ms_per_token, decode_tps) to estimate TTFT/TPS. See docs/benchmark_platform.md.

Visualization (M8)

cargo run -p forgesim-cli -- run \
  --config configs/clusters/small_h100.yaml \
  --jobs-output outputs/jobs.json

pip install -e '.[viz]'
python python/examples/plot_run.py outputs/jobs.json

Live CLI dashboard (Phase 1 UI)

Rich terminal dashboard — see docs/ui_dashboard.md for full setup, scripts, and troubleshooting.

./scripts/setup_dev.sh
./scripts/run_live_dashboard.sh --config configs/clusters/small_h100.yaml

Web dashboard (Phase 2 + benchmark UI)

FastAPI + Next.js — see docs/ui_dashboard.md for API reference and scripts.

./scripts/setup_dev.sh
cd web && npm install && cd ..
./scripts/run_web_dashboard.sh    # http://localhost:3000

Routes: / (runs + compare), /benchmark, /what-if, /login. Or run API and UI separately: ./scripts/run_web_api.sh · ./scripts/run_web_ui.sh

Deploy (Docker / Kubernetes)

./deploy/build-images.sh
kubectl apply -k deploy/kubernetes

See docs/deploy.md and deploy/kubernetes/README.md.

Python + RL (M7)

On macOS Homebrew Python, use the setup script if venv fails on pyexpat:

./scripts/setup_dev.sh
source .venv/bin/activate
pip install -e '.[rl]'
python python/examples/run_rl_env.py
python python/baselines/ppo_cleanrl.py --config configs/clusters/rl_small.yaml

AIPerf calibration (P7)

PYTHONPATH=python python -m forgesim.benchmarks.aiperf_adapter \
  import tests/fixtures/aiperf/sample_result.json --profile llama-70b

OpenAI-compatible shim (P6)

With the web API running (./scripts/run_web_api.sh):

curl -s http://127.0.0.1:8080/v1/chat/completions \
  -H "Authorization: Bearer dev-forgesim-key" \
  -H "Content-Type: application/json" \
  -d '{"model":"llama-70b","messages":[{"role":"user","content":"hi"}],"stream":false}'

See docs/openai_shim.md.

Test layout

Layer	Location	What it covers
Rust unit	`crates/*/src/` (`#[test]` modules)	Models, MIG, resource manager, FIFO, trace parsing
Rust integration	`crates/forgesim-config/tests/integration.rs`	Full sim pipelines (YAML, Forge bundle, trace, MIG, RL, topology)
CLI integration	`crates/forgesim-cli/tests/cli_integration.rs`	`forge-sim run` / `replay` binary
Python unit	`python/tests/test_unit_adapters.py`	CRD mapping, profiles, bundle, trace adapters
Python integration	`python/tests/test_integration_cli.py`	CLI via `cargo run -p forgesim-cli`
Benchmark / UI	`python/tests/test_benchmark`, `test_server_`, `test_openai_`	API, shim, AIPerf, score

cargo test --workspace --exclude forgesim-py
cargo test -p forgesim-config --test integration
cargo test -p forgesim-cli --test cli_integration
PYTHONPATH=python python3 -m unittest discover -s python/tests -v
bash benchmarks/ci/run_golden.sh

Project layout

crates/              Rust workspace (core, scheduler, config, metrics, cli, py)
python/forgesim/     Adapters, envs, viz, dashboard, server, benchmarks, workloads
web/                 Next.js web dashboard (/ , /benchmark, /what-if)
scripts/             setup_dev.sh, run_*_dashboard.sh, clean.sh
deploy/              Docker images + Kubernetes manifests
benchmarks/ci/       Golden sim regression script
configs/
  profiles/          Calibrated model runtimes (v1 + inference v2)
  clusters/          Cluster + workload YAML examples
  analytics/         Cost model (score weights optional)
tests/fixtures/      Forge, traces, AIPerf, benchmark goldens
docs/                Architecture, milestones, UI, benchmark platform, deploy

Milestones

See docs/milestones.md. M1–M8 complete, including topology runtime inflation, gang timeout, RL (M7), and visualization (M8).

Benchmark platform (MVP shipped): docs/benchmark_platform.md — inference model, serving traces, score vector, /benchmark + /what-if UI, OpenAI shim, AIPerf adapter, twin store API, CI golden script. Remaining gaps (full sim-vs-measured UI, CLI --serving-trace, twin library page) are listed in that doc and the manual test guide.

Schedulers: fifo, priority, preemptive, forge (alias for preemptive), bestfit.

Dual-node “migrate” demo (placement, not live CUDA)

Preemptive scheduler moves a low-priority job across machines after preemption:

cargo run -p forgesim-cli -- run --config configs/clusters/dual_node_preempt.yaml
# Dashboard + wow reel (writes ~/Desktop/forgesim-client-dual-node-migrate-wow-reel.mp4)
./scripts/run_web_dashboard.sh   # separate terminal
FORGESIM_DEMO_CONFIG=dual_node_preempt.yaml \
  node scripts/demo-videos/record-forgesim-2gpu-migrate-wow-reel.mjs

This is a digital-twin placement migrate. Forge’s production live migrate is KubeVirt VMs (Path A); pod checkpoint/restore is experimental Path B — see Forge docs/product/POD_VS_VM_MIGRATION.md.

Forge input

See docs/forge_input.md for CRD mapping rules, export workflow, and adapter levels.

License

Apache-2.0 — see LICENSE.
