FenestRA

Fenestration Resolution & Analysis Pipeline

FenestRA is a custom Napari plugin built for the Advanced LSEC AFM Pipeline. It bridges the gap between interactive Napari features, legacy deep-learning upscale repositories via containerized backends, and state-of-the-art Cellpose instance segmentation.

By combining Deep Learning-based Super Resolution (HAT / SwinIR) with automated morphological analysis, FenestRA drastically simplifies the workflow of extracting robust physical porosity and fenestration morphology metrics directly from raw .jpk.qi-image files.

Important

Pre-Publication Notice
This repository provides the public codebase and scaffolding for the FenestRA pipeline. The fine-tuned deep learning model weights (specifically for the HAT, SwinIR, and custom Cellpose LSEC segmentation models) are currently kept private. They will be made completely publicly available alongside the peer-reviewed manuscript immediately upon its formal publication.

---

Features

• Cross-Platform Container Engine: Seamlessly toggle between Docker (Windows / macOS) and Singularity / Apptainer (Linux / HPC) directly from the Napari UI. No code changes needed when switching platforms.
• Hub-and-Spoke Deep Learning Architecture: Run legacy Python 3.8 dependent upscale models (HAT, SwinIR) asynchronously inside a container without freezing your modern Napari GUI.
• Post-DL Image Enhancement: Optional CLAHE contrast equalization and Unsharp Masking applied directly to the Deep Learning output to sharpen fenestration edges before segmentation.
• Native JPK Ingestion: Automatically reads native physical scale (nm / px) from .jpk.qi-image files using AFMReader.
• Synchronized 4-Pane Analysis: Auto-generates a synchronized Napari viewer layout combining Raw, Upsampled, Mask, and Boundary Overlays natively.
• Configurable CPU Fallback: Includes high-fidelity Python-based CLAHE and unsharp masking functions when DL inference isn't required.
• Sub-cellular Quantification: Automatically calculates standard metrics (area, perimeter, equivalent diameter, eccentricity, porosity) with digital-to-physical size translations directly to .csv.
• Batch Analysis: Process an entire folder of .jpk-qi-image files in one automated run. Produces a single consolidated .xlsx Excel file with metrics from all images, plus individual upsampled TIFFs and Cellpose mask TIFFs.

---

Installation

Tip

These are the condensed steps. The documentation site walks through the same install with per-package explanations, a verification checklist, and a troubleshooting page indexed by error message. Build it locally with bash website/serve.sh (see Documentation).

1. Requirements

• Python 3.10+
• An NVIDIA GPU with CUDA 12.4 drivers (recommended for DL inference)

Caution

Hardware Compatibility Warning: FenestRA requires deep learning hardware capable of running modern tensor operations. Extremely old legacy GPUs based on the Maxwell architecture (Compute Capability 5.2 or earlier, such as the Quadro M4000) physically lack hardware support for BFloat16 (CUDA_R_16BF) math. Running the plugin on these ancient GPUs will cause PyTorch and Cellpose to instantly crash with a CUBLAS_STATUS_NOT_SUPPORTED error.

• Linux: Apptainer / Singularity
• Windows / macOS: Docker Desktop

2. Create the Host Environment

Create a clean Anaconda environment optimized for Cellpose targeting CUDA 12.4:

conda create -n fenestra-env -c conda-forge python=3.10 numpy=1.26.4
conda activate fenestra-env

# Install base GUI tools, Napari, and core scientific dependencies
pip install "napari[all]" magicgui qtpy scipy scikit-image pandas tifffile "numpy<2" openpyxl

# Install PyTorch mapped explicitly to CUDA 12.4 to ensure GPU hardware acceleration works
pip install --index-url https://download.pytorch.org/whl/cu124 torch==2.4.0 torchvision==0.19.0

# Install Cellpose for fenestration instance segmentation
pip install cellpose

# Install AFMReader for handling raw JPK AFM metadata
pip install git+https://github.com/AFM-SPM/AFMReader.git

3. Install FenestRA

Since FenestRA is now available as a Python package on PyPI, you can install it directly using pip:

pip install napari-fenestra

# To update an existing installation to the latest version, run:
pip install --upgrade napari-fenestra

Important

Step 2 is not optional. The published package does not declare napari, AFMReader, or torch in install_requires, even though all three are imported at runtime. Installing napari-fenestra on its own therefore leaves you with no viewer to dock into and no .jpk reader. AFMReader is distributed from git rather than PyPI, which is why it cannot be declared as an ordinary dependency. torch does arrive indirectly via cellpose, but as the default PyPI wheel rather than the CUDA 12.4 build from step 2, so you lose GPU acceleration.

4. Setup the Deep Learning Backend (Docker vs Singularity)

FenestRA runs its massive deep learning architectures completely independently from the modern Napari UI. You must compile the container engine based on your Operating System.

Warning

The Docker engine path is currently broken. containers/Dockerfile ends with ENTRYPOINT ["python"], and pipeline.py also passes python as the first element of the command. Docker concatenates ENTRYPOINT and CMD, so the container tries to run python python /opt/dl_project/scripts/inference.py and exits with:

can't open file '/opt/python': [Errno 2] No such file or directory

Either fix works, and only one is needed: set ENTRYPOINT [] in the Dockerfile and rebuild, or remove the "python" element from the Docker argv list in src/fenestra/pipeline.py (it appears twice, in the interactive block and the batch block, and both must be changed).

The Apptainer / Singularity path is unaffected: singularity exec bypasses the container's %runscript, so the explicit python is required there. That is why the two engines need different argv.

First, clone the repository to download the Docker and Singularity setup files:

git clone https://github.com/LIVR-VUB/FenestRA.git
cd FenestRA

For Windows & macOS Users (Docker Desktop): Because Apple and Windows systems cannot securely install Singularity, we use Docker.

1. Install Docker Desktop on your machine.
2. Open a terminal and navigate to this repository's containers/ directory.
3. Build the backend image (Windows/Mac users do NOT need sudo):

docker build -t livrvub/dl-upsampling:latest -f Dockerfile ..

(In Napari, select Docker from the Engine dropdown. No file browsing needed!)

For Native Linux Users (Singularity / Apptainer): Linux systems heavily restrict Docker permissions. For ultimate performance and hassle-free paths on Linux, use Apptainer/Singularity.

1. Install Apptainer natively on your Linux distribution.
2. Open a terminal and build the container using the provided definition recipe:

sudo apptainer build dl_upsampling.sif containers/dl_upsampling.def

(In Napari, select Singularity from the Engine dropdown, and use the ... button to select that .sif file!)

---

Usage

Single Image Analysis

1. Activate your environment: conda activate fenestra-env
2. Launch napari: napari
3. Navigate to Plugins > FenestRA Pipeline to open the widget!
4. Step 1 — Input Data: Load your *.jpk-qi-image file.
5. Step 2 — Upsampling: Select a method (CLAHE, HAT, or SwinIR). For DL methods, specify the model .pth, choose your Engine (Docker or Singularity), and optionally enable "Apply Post-DL Sharpening" with adjustable Clip Limit and Unsharp parameters. Hit Run Upsampling.
6. Step 3 — Segmentation: Configure Cellpose parameters (Diameter, Cellprob Threshold, Flow Threshold). Optionally load a custom Cellpose model. Hit Run Cellpose.
7. Step 4 — Layout & Analysis: Click Arrange 4-Pane Grid for a synchronized review of Raw, Upsampled, Mask, and Overlay views. Click Quantify Fenestrations to export your CSV metrics.

Batch Analysis

1. Configure your preferred upsampling method, model paths, and Cellpose parameters using the single-image sections above.
2. Scroll down to Section 5 — Batch Analysis.
3. Select an Input Directory containing your .jpk-qi-image files.
4. Select an Output Directory where results will be saved.
5. Click Run Batch. The status label will update in real-time showing progress (e.g., Processing 3/10: sample.jpk-qi-image).
6. When complete, the output directory will contain:
   • batch_results.xlsx — Consolidated Excel file with metrics from all images (with Image_Name column).
   • <image_name>_upsampled.tif — Upsampled TIFF for each input image.
   • <image_name>_mask.tif — Cellpose segmentation mask for each input image.

---

Documentation

A full handbook lives in docs/ and builds into a searchable MkDocs Material site covering installation, a screenshot-led walkthrough of all five panels, a parameter and output reference, the pixel-to-nanometre arithmetic, and the scientific caveats that affect what the measurements support.

The site builds inside its own small CPU-only container, fully isolated from the DL/GPU stack:

# Build the docs image once (~200 MB, no CUDA or torch)
apptainer build website/docs.sif website/docs.def

# Live preview at http://127.0.0.1:8000 (local only, nothing is published)
bash website/serve.sh

# Or render the static site into ./site
bash website/build.sh

Both site/ and website/docs.sif are gitignored build artefacts.

---

Changelog

v0.2

• Batch Analysis Module: New Section 5 in the Napari UI for processing entire folders of .jpk-qi-image files. Outputs a single consolidated .xlsx Excel file with fenestration metrics from all images, plus individual upsampled TIFFs and Cellpose mask TIFFs.
• Post-DL Image Enhancement: Added an optional "Apply Post-DL Sharpening" checkbox that applies CLAHE contrast equalization and Unsharp Masking to the Deep Learning output before Cellpose segmentation.
• UI Restructuring: Separated the Clip Limit / Unsharp Radius / Amount sliders into a shared post-processing group that is dynamically visible for both CLAHE and DL workflows.

v0.1

• Cross-Platform Docker Support: Added a Dockerfile mirroring the Singularity .def environment. Users can now toggle between Docker and Singularity engines directly from the Napari UI.
• Engine Toggle UI: New "Engine" dropdown in the Upsampling section. Selecting Docker shows a tag input; selecting Singularity shows a .sif file picker.
• Container Recipes: Both Dockerfile and dl_upsampling.def are now bundled in the containers/ directory.
• Cross-Platform README: Added installation instructions for Windows, macOS, and Linux users.

---

Acknowledgments & Citations

If you use FenestRA in your research, please ensure you properly cite the core technologies that make this pipeline possible:

• Cellpose (Instance Segmentation Engine):

  Stringer, C., Wang, T., Michaelos, M., & Pachitariu, M. (2021). Cellpose: a generalist algorithm for cellular segmentation. Nature Methods, 18(1), 100-106. https://doi.org/10.1038/s41592-020-01018-x

• AFMReader (JPK File Ingestion):

  Our native support for .jpk-qi-image AFM files is powered by the AFMReader library maintained by the AFM-SPM community.

• HAT / SwinIR (Generative Deep Learning Models):

  Chen, X. et al. (2023). Activating More Pixels in Image Super-Resolution Transformer. (HAT) Liang, J. et al. (2021). SwinIR: Image Restoration Using Swin Transformer.

---

This project has received funding from the European Union’s Horizon research and innovation programme under the Marie Skłodowska-Curie grant agreement No 101119613, as part of the ImAge-d MSCA Doctoral network.
